China 60100458-J K3V112DTP-9TEL Hydraulic Pump

Model: K3V112DTP-9TEL
Type: Axial piston pump with swash plate design and negative flow control
Displacement: 112 cc/rev
Maximum flow rate: 252 L/min (67 gallons per minute)
Maximum pressure: 34.3 MPa (4972 psi)
Weight: 92.5 kg (204 lbs)
Shaft: Keyed, tapered
Ports: SAE flange
Control type: Hydraulic servo or hydraulic pilot
Rotation: Clockwise (viewed from shaft end)
Drive type: Via coupling flange, splined shaft or keyed shaft
